Description
Copper foil is an indispensable material in the current electronic industry, first and foremost in the EV and 5G industries. As a result of recent rapid technological innovation, high-grade copper foil is in significant demand across various electronic industries. Applications of copper foil include conductive material for circuit boards, current collectors for lithium-ion batteries,and shielding material for displays.
In recent years, electric vehicles have come under the spotlight due to a worldwide shift towards clean energy. The demand for copper foil is rapidly increasing since it is used in the lithium-ion battery, a critical component of electric vehicles.
Product Specification
| Copper foil | ||
| Item | Data | |
| width (mm) | 280 mm, other width can be customized | |
| Thickness (um) | 8 um / 9 um /10 um, other size optional | |
| areal density (g/m2) | 85-90 | |
| Purity(%) More than 99.9% | Cu ≥99.9% | |
| Fe < 0.0010% | ||
| Bi < 0.00020% | ||
| Pb < 0.0005% | ||
| Tensile strength (MPa) | ≥294 | |
| Normal elongation(%) | 2.5 | |
| High temperature Tensile strength180℃(MPa) | ≥147 | |
| High temperature elongation180℃(%) | 2 | |
| Anti oxidization(180℃ Heating 1h) | No oxidation of points on the surface, The color does not change, Copper foil without fracture |
|
| Surface roughness(um)Rz | Drum side(um) | Less than 0.3 |
| Matte side(um) | Less than 3.0 | |
| Surface tension(dyne/cm) | Drum side | 62 |
| Matte side | 62 | |
| Coating performance | Cu foil with uniform tension on both sides, slurry coating uniform | |
Electrodeposited Copper Foil Applications
Copper foils are suitable for a range of applications, from PCB’s to lithium-ion batteries. Electrodeposited copper foil is one of the most essential components in PCB’s, as the conductive material of the printed circuit board, and also plays an important role as the anode material of the lithium-ion battery.
Electrodeposited Copper Foil Manufacturing Process
Electrodeposited copper foil is manufactured through the deposition of copper ions, onto the cathode drum via electrolysis. In Practice, the foil is produced through continuous rotation of the drum and simultaneous winding of the copper foil as it is released from the drum surface.
