Description
Our copper strip is manufactured in compliance with the main international specifications.
Tighter tolerances are available upon request. Custom tempers are available upon request.
Manufactured in compliance with the main international specifications and standards including: ASTM, EN, and DIN. Our brass strip can also be manufactured to meet the requirements of other international standards, including: ASME, SAE, MIL, QQ, ISO, BS, and JIS.
| Alloy Grade | Material Characteristics | Application | ||||||
| C11000 Cu≥99.90 |
It has good electrical conductivity, heat conduction, corrosion resistance and processing properties. It can be welded and brazed. The impurities and trace amount of oxygen only have very few effect on electrical and thermal conductivity. But the trace oxygen is easy to cause "hydrogen disease", so it can’t be processed and used in high temperature (such as > 370℃). |
Widely used for electric, heat conduction, corrosion resistance equipment. Such as: wire, cable, conductive screw, blasting detonator, chemical evaporator, storage device and a variety of pipes etc. |
||||||
|
C10200
Cu≥99.97 C10300 Cu≥99.95 |
High purity, excellent electrical and thermal conductivity, barely no "hydrogen disease", good processing, welding, corrosion resistance and cold resistance performance. |
Mainly used for electrical vacuum instruments, all kinds of hardware products, lamps, pipe fittings, zippers, plaques, nails, springs, sedimentation filters etc. |
||||||
| C12000, C12200 Cu≥99.90 |
Good welding and cold bending performance. It can be processed and used in reducing atmosphere, but not in oxidizing atmosphere. C12000 has less residual phosphorus than C12200, so its thermal conductivity are higher than C12200. |
Mainly used for pipe applications, such as gasoline or gas conveying pipe, drain pipe, condensate pipe, mine pipe, condenser, evaporator, heat exchanger, train parts. It also can be processed to plate, strip, tape and rod. |
||||||
Surface Finishes
Oil-free surface
Electro plating
Hot-dip tin plating
Deburred or rounded edges
Bright and polished surfaces
Strip with protective coatings
Profiled strip by either milling or stamping
Application
Mainly used for transformer installation, high and low voltage open cabinet, vacuum appliances, enclosed mother slot, generator and bus, rectifier equipment, rectifier cabinet and disconnector connection.
